Electrolyzer of thirty m3 water electrolysis hydrogen production equipment
Contact Freely
Email: sales1@zxdh2.com
Skype: jessica01235483 | WhatsApp (Tel): 86-18030235311
Product Description
|
P/N
|
ZXD-30
|
|
Hydrogen Production（m3/h）
|
30
|
|
Oxygen Production（m3/h）
|
15
|
|
Hydrogen Purity（V/V）
|
≥99.8%
|
|
Oxygen Purity （V/V）
|
≥92.5%
|
|
Operating load
|
50%~100%
|
|
Working Pressure（MPa）
|
1.5~2.0
|
|
Hydrogen Moisture Content （g/m3）
|
≤4
|
|
Hydrogen Alkalinity（mg/m3）
|
≤1
|
|
Working Temperature（℃）
|
85±5
|
|
Cooling water flow（m3/h）
|
4.2
|
|
DC power consumption
(kW·h/m3H2)
|
≤4.6
|
|
External dimension of electrolyzer
L×W×H （mm）
|
2180×1160×1400
|
|
Electrolyzer Weight （kg）
|
4800
|
|
Alkali concentration
|
30% KOH
|
|
Circulation quantity of alkali liquor
（m3/h）
|
2.0~2.5
|
|
KOH consumption (normal operation（kg/unit）
|
320
|
Company Introduction
The
ZXDH series hydrogen generator produced by Zhongxinda has a capacity
from 2 to 250m3/h, and uses a new programmable logic controller (PLC) to
achieve control.
Provide
users with an efficient, reliable and safe hydrogen production system.
The hydrogen generator launched by the company also has a variety of
control methods and auxiliary equipment options.
It is available for users to configure according to the best working conditions.
Xiamen Zhongxinda Hydrogen Energy Technology Co., Ltd
Product Description
The
electrolytic cell body is a bipolar filter press type plate and frame
structure, adopts a special sealing structure and materials, and has no
leakage in long-term operation.
The high operating pressure of the device saves the investment in compressors and large-capacity wet storage tanks.
The load adaptability is strong, and the operating pressure and output are continuously adjustable below the rated value.
The current efficiency is high, and the energy consumption is much lower than that of the atmospheric tank.
Microprocessor control, automatic operation, complete fault alarm protection function.
All
parts in contact with media are made of high-quality stainless steel or
nickel-plated on the surface to improve corrosion resistance.
long lasting.
It
is small in size and light in weight. The whole set of generator is
assembled with an integrated frame structure, which is convenient for
installation and transportation.
Complete supporting facilities and diverse options can help users obtain the best economical configuration.
