Product Description
Performance
Performance Index of Water Electrolysis Hydrogen Production Equipment
Hydrogen Production 5m3/Nh
Oxygen Production 2.5m3/Nh
Hydrogen Purity ≥99.9%
Oxygen Purity ≥99.9%
System Working Pressure 2.5～3.2MPa
Electrolyzer Working Temperature 80～85℃
Electrolyzer Rated Working Current DC500A
Electrolyzer Rated Working Voltage DC48V
Xiamen Zhongxinda Hydrogen Energy Technology Co., Ltd
**** | sales1@zxdh2.com
Technical Specifications
|
ZXD Hydrogen Purification Plant
|
|
P/N &Specification
|
ZXD1500
|
|
Treatment capacity m3/h
|
1500
|
|
Working Pressure MPa
|
0.8-1.6
|
|
Working Temperature
|
Deoxidation℃
|
80-100
|
|
Dry℃
|
10
|
|
Regenerate℃
|
250
|
|
Cooling Water Volume t/h
|
18
|
|
Power Consumption KW
|
18
|
|
Instrument Gas Consumption m3/h
|
5
|
|
Product gas
|
Moisture content (dew point)
|
≤-75℃
|
|
Oxygen Content（ppm)
|
≤2
|
|
Control Mode
|
PLC Fully Automatic
|
|
External dimension
|
4.8×2.2×3.2
|
|
Length × Width × Height (m)
|
|
Unit Weight(t)
|
6
|
|
Remarks : Product hydrogen Regeneration-type,Three towers-type
|
Company Information
The
electrolytic cell body is a bipolar filter press type plate and frame
structure, adopts a special sealing structure and materials, and has no
leakage in long-term operation.
The high operating pressure of the device saves the investment in compressors and large-capacity wet storage tanks.
The load adaptability is strong, and the operating pressure and output are continuously adjustable below the rated value.
The current efficiency is high, and the energy consumption is much lower than that of the atmospheric tank.
Microprocessor control, automatic operation, complete fault alarm protection function.
All
parts in contact with media are made of high-quality stainless steel or
nickel-plated on the surface to improve corrosion resistance.
long lasting.
It
is small in size and light in weight. The whole set of generator is
assembled with an integrated frame structure, which is convenient for
installation and transportation.
Complete supporting facilities and diverse options can help users obtain the best economical configuration.
