Electrolyzer for hydrogen production from water electrolysis
Xiamen Zhongxinda Hydrogen Energy Technology Co., Ltd
Sales manager: Jessica
Email : sales1@zxdh2.com | Skype: jessica01235483
WhatsApp: +86-18030235311 | Wechat: hu18030235311
Specification parameters
P/N |
ZXD-1000 |
Hydrogen Production(m3/h) |
1000 |
Oxygen Production(m3/h) |
500 |
Hydrogen Purity(V/V) |
≥99.99% |
Oxygen Purity(V/V) |
≥92.5% |
Operating load |
50%-100% |
Working Pressure(MPa) |
1.5~2.0 |
Hydrogen Moisture Content(g/m3) |
≤4 |
Hydrogen Alkalinity(mg/m3) |
≤1 |
Working Temperature(℃) |
85±5 |
Cooling water flow(m3/h) |
150 |
DC power consumption(kW·h/m3H2) |
≤4.3 |
External dimension of electrolyzer L×W×H (mm) |
7730x2325x2750 |
Electrolyzer Weight(kg) |
60600 |
Alkali concentration |
30% KOH |
Circulation quantity of alkali liquor(m3/h) |
56~66 |
Koh consumption (normal operation)(kg/unit) |
8300 |
Equipment introduction
The pneumatic regulating diaphragm valve imported from the United States is used to regulate the working pressure, the pressure difference between the level of H2 alkali and the level of O2 alkali and the working temperature.
All
on-line analyzers (including the percentage of H2 in the O2 analyzer
and the percentage of O2 in the H2 analyzer) are sensed by GE USA to
monitor the gas purity and send an alarm / interlock system signal when
any poor purity is found in the gas.
PLC
control and monitoring unit (according to user requirements)
configuration, easy to operate human-computer interface for operators to
operate and monitor hydrogen generator, including data collection and
display, historical data recording and trenching, alarm and interlock,
operation priority classification, etc., fully ensure the safety and
reliability of hydrogen gas generator.
Technical specifications |
Unit |
Specification |
H2 rated flow |
Nm3 / h |
Nm3 / h |
Operating pressure |
MPa |
1.5 |
Business Scope |
% |
50 ~ 100 |
H2 purity |
% |
99.999 |
Track the O2 content in H2 |
parts per million |
less than 2ppm |
Dew point of H2 |
unit ℃ |
better than - 70 ° C |
Our Web: **** style="font-size:24px;font-family:"color:#E53333;">
Company profile
The
ZXDH series hydrogen generator produced by Zhongxinda has a capacity
from 2 to 250m3/h, and uses a new programmable logic controller (PLC) to
achieve control.
Provide
users with an efficient, reliable and safe hydrogen production system.
The hydrogen generator launched by the company also has a variety of
control methods and auxiliary equipment options.
It is available for users to configure according to the best working conditions.
The company's products are used in hydrogen refueling stations, new energy, chemical, non-ferrous metals,
electric power, steel, aviation and other industries, and are sold globally, such as the United States,
South Korea, Belarus, India, Pakistan, Turkey, Saudi Arabia, Vietnam, Indonesia, Nigeria, South Africa ,
Taiwan and many other countries and regions.
